3 gable timber pavilion architectural style.
Build this 3-gable timber pavilion at the end of your pool or in the corner of the yard. This open-air structure plan provides you with a very stylistic three gable frame pavilion that you can put a dining table under, living area, grill on one of the ends or, even a fireplace.
This frame will set well in the corner of a garden in the backyard of your property.
This pavilion plan can serve as a good design to submit to your local HOA or architectural review board for a very affordable fee!
Build it DIY with our plans.
If you want to give it the go ahead with building this yourself or purchasing the plans for your builder, we have you covered in both cases.
This plan is developed by trained carpenters and is clear and thorough. Its design it meant to promote an open air structure to last your lifetime.
Within your purchase of this plan we provide the following:
- Architectural Plans, Elevations, and Sections
- Joinery Notes and Call Out
- Timber Material Lists
- Roofing Surface and Floor Finish Areas
- Drip Edge Linear Feet Take Off
- Colored Renderings
We will send you the interlocking kit.
If you love it but prefer not to take on the project of gathering the timber and cutting it, we can expedite your project by sending you the timber frame kit built of mortise and tenon joinery with hardwood pegs. This interlocking construction and self-registering pieces goes together without any measuring.
F.A.Q.
Why purchase this plan from Joint and Peg?
You will be empowered to build from the plans yourself or have the work quoted by others. Having these options puts you in an advantageous position for your project.
What is included in this 3 Gable Timber Pavilion by Joint and Peg?
When you purchase this plan you will receive at a minimum: a timber list for ordering materials, plan views, elevations, sections, and detailing to construct the project with authentic timber frame joinery. All drawings and lists for this 3 Gable Timber Pavilion are delivered instantly via email and download links.
I want to build this myself. Is this plan a good fit for me?
That depends on your skill level. One of our goals is to open the doors of timber framing to builders, carpenters, and DIY’s. The best of designs still requires a certain baseline of the builder to be able to know the basic concepts of construction. That said, if you have those basic skills and this 3 Gable Timber Pavilion at your side, you are prepared to accomplish the project! It’s up to you at that point to get started!
What if I want to have someone else build it? Will the plans be good for that too?
Absolutely! Your builder/contractor/tradesperson should be ecstatic to see this 3 Gable Timber Pavilion as it will be easy for them to accurately gauge the work, and the materials required. This translates to you receiving an accurate quote from them.
What is a part of timber framing that is commonly overlooked?
Timbers are heavy! Timbers are not 2x lumber that can be easily lifted. Material handling is often underestimated when it comes to timber frame projects. The smallest timbers typically are 4×6. Planning to work with material that is heavy is imperative. A good mind for logistics and staging is well suited for this craft.
What if I don’t want to or can’t build with timber frame joinery?
Some of our plans include options for both timber frame joinery and metal hardware connections. Whether this is available for this 3 Gable Timber Pavilion is clarified in the description above.
That is great but can Joint and Peg build it for me?
If you are in our local service area. Joint and Peg can provide this 3 Gable Timber Pavilion as a built turnkey timber frame packages for the Charleston, SC area. Please inquire with us if you would like more information on pricing and scheduling.
Important Info
Every state, county or municipality will have its own building and code requirements as environments differ from one region to the next. It is possible that your plan may need to be modified to comply with these local requirements and conditions. This is particularly true in coastal areas and those facing seismic events, extreme winds, and heavy snow.
If you are building in any of these areas and depending on the size and purpose of the structure, it is likely that a licensed structural engineer will be needed to provide the necessary calculations and stamp.
All pre-drawn plans from Joint and Peg do not carry a stamp from a licensed architect or a licensed engineer. Please understand that we will not be held responsible for the performance and suitability of this design plan as we don’t know the criteria with where you plan to build, nor the material to be used, nor any additional structure to be implemented in the construction.
If this is a requirement from your local building department, or it proves to be the prudent thing to do, Joint and Peg can provide you state sealed engineered drawings for an additional fee. When it comes to the time to build, we highly recommend that you enlist our engineering service. Otherwise, the onus of this structure’s performance is solely with others, not Joint and Peg.
Single Use Terms
We authorize the use of our plans for one single project; conditioned on your obligation and agreement to comply with all local building codes, ordinances, regulations, and requirements, including permits and inspections at the time of and during construction. Multiplied use of our plans is prohibited. Thank you.
30 Day Guarantee
Joint and Peg is committed to satisfying our customers with a quality product and service. We will provide refund for this 3 Gable Timber Pavilion under the following conditions:
- Full refunds on downloaded plans within 30 days of purchase minus a $10 processing fee.
- Full refunds on shipped plans within 30 days of purchase minus a $10 processing fee + the shipping and handling fee.
- We request that you fill out a brief questionnaire to better understand your dissatisfaction and/or reason for the return. This is optional for you, but we would appreciate your reasons for the refund request.
- Engineered Construction Plans sales are final.
After 30 days, all plan sales are final. Please be sure that you have chosen the best plan to suit your needs and have received answers to your questions before making the purchase.
You can call us so we can assist with basic questions, and we are here Monday-Friday, 9-5EST to speak with you.
You can also email us at [email protected]
Specifications
Base Frame Plan
Download File 1
Base Frame Plan: Letter Size Sheets (8 ½” x 11”) – Qty: 13
- Notes
- Plan Views
- Elevations
- Sections
- Call Outs
- Dimensions
- Parts Numbers
- Foundation Detail
Download File 2
Material Lists: Letter Size Sheets (8 ½” x 11”) – Qty: 4
- Wood List
- Concrete List
- Square Foot Areas
Plan with Joinery Details
Download File 3
Single Beam Drawings: Letter Size Sheets (8 1/2″x 11″) – Qty: 32
- Introduction
- Single Beam Drawings
- Dimensions
Typical Timber Sizes
- 4×6 Timbers
- 6×6 Timbers
- 6×8 Timbers
- 6×10 Timbers
- 8×8 Timbers
